A magnet that is only a few millimetres wider can make the difference between a cabinet door that closes cleanly and one that springs open. This N52 magnet size guide explains how to choose the right dimensions and format for the holding job, rather than simply buying the largest magnet available.

N52 neodymium magnets are among the strongest commonly available magnet grades. That makes them ideal where space is limited but holding power matters. However, the grade alone does not determine performance. Diameter, thickness, shape, contact area, fixing method and the material being attracted all affect the result.

What N52 means for magnet size

N52 refers to the magnet grade, not its physical dimensions. It indicates a high magnetic energy level, allowing a relatively small magnet to provide superior pull performance compared with lower-grade alternatives of the same size.

A 10 mm diameter N52 disc and a 20 mm diameter N52 disc are both N52, but their holding performance will be very different. The larger disc has more magnetic material and a greater contact area. Likewise, making a magnet thicker usually increases its pull force, although the gain is not always linear once the magnet is already thick enough for the application.

For practical buying, think of N52 as the strength of the material and the dimensions as the amount of that material available to do the work. A compact N52 magnet can be extremely powerful, but it still needs sufficient size for the load, gap and surface involved.

N52 magnet size guide: read the dimensions correctly

Disc magnets are normally shown as diameter x thickness. A 10 mm x 3 mm disc is 10 mm across its circular face and 3 mm deep. Increasing the diameter usually has the biggest effect when the magnet will sit flat against a steel plate. Increasing thickness is useful where the magnet needs more reach or where a slightly wider disc will not fit.

Block magnets are typically listed as length x width x thickness. A 20 mm x 10 mm x 3 mm block gives a long, narrow contact area, which can suit catches, signs, tool holders and timber work where a round magnet is less convenient. The final figure is usually the thickness, but always check the product dimensions before machining a recess.

Countersunk magnets have an additional measurement to consider: the screw-hole size. The outside diameter must fit the available fixing area, while the countersink needs to suit the screw head. A screw that sits proud can prevent the magnet from meeting the steel surface properly, reducing the hold and leaving an untidy finish.

When comparing sizes, allow for the full installation. A magnet may fit inside a routed pocket, but the mating plate, screw head, adhesive layer or door alignment may still create a gap. Even a small air gap can noticeably reduce magnetic attraction.

Choose the right format before choosing the size

The best N52 magnet is not always the one with the highest quoted pull force. The format should match how it will be installed and loaded.

N52 disc magnets

Disc magnets are a strong all-round choice for concealed catches, removable panels, display work, craft fixtures and compact workshop solutions. Their circular shape is easy to drill or route for, and a flat disc presents a broad face to a steel plate.

For light closures, a small disc may be enough where surfaces meet accurately. For a cupboard door, access panel or heavier timber flap, move up in diameter or thickness rather than relying on a very small magnet to do too much. A pair of moderate-sized discs can also give a more controlled closure than one oversized magnet, particularly on wide doors.

N52 block magnets

Block magnets suit applications that need directional holding power or a rectangular mounting footprint. They are useful in jigs, retail displays, timber frames, tool storage and custom fabrication. Their straight edges can make alignment easier when fitting into a channel or recess.

A longer block can spread holding force over a wider area, helping to reduce twisting on a panel. For a narrow edge, though, a slimmer block may be more practical than a large disc. Check that the timber around the recess remains strong enough, especially in thin MDF, plywood or veneered board.

N52 countersunk magnets

Countersunk magnets are designed for secure mechanical fixing. They are a practical option for cabinet catches, gates, removable signs, display units and any installation where adhesive alone is not suitable.

The screw should be non-magnetic where possible if you want the magnet’s face free to attract a separate steel plate. Ferrous screws can affect the local magnetic circuit, though they may also be perfectly acceptable in a fixed mounting arrangement. The key point is to use a screw head that sits flush and to avoid overtightening, as neodymium magnets are hard but brittle and can crack under point pressure.

Do not select by pull force alone

Quoted pull force is useful for comparison, but it is measured under favourable conditions: direct contact with clean, thick mild steel and a straight pulling action. Most real installations are less forgiving.

A cabinet magnet may work across a paint layer, veneer, adhesive pad or a slight misalignment. A vertical sign creates a sliding load rather than a direct pull. A door that is pulled sideways can shear away from the magnet more easily than one pulled straight off it. These differences mean a magnet with a quoted pull force well above the expected load is usually the safer choice.

For closure applications, excessive strength can be a problem too. A very powerful magnet may make a lightweight cupboard difficult to open, pull a thin steel strike plate out of alignment or cause fingers to be caught during fitting. The right size is the smallest option that delivers reliable holding with a sensible release force.

Size choices for common jobs

For small cabinet doors and lightweight access panels, compact discs or small countersunk magnets often provide a neat, concealed result. The exact size depends on the door weight, hinge quality and the gap at the closing edge. If the door is warped or has a large gap, improving the fit may be more effective than simply fitting a larger magnet.

For heavier cupboard doors, larger discs, larger countersunk magnets or two fixing points are often more reliable. Two magnets positioned apart can resist twisting and stop one corner from lifting. This is particularly useful on tall doors and wide retail-unit panels.

For removable signs and display panels, use a larger face area where possible. A thin, broad disc or block may hold more predictably than a narrow, thick magnet because it contacts more of the steel surface. If the panel is vertical, account for sliding force and test the fixing on the actual material before committing to a production run.

For workshop jigs and tool holders, block magnets are often the practical choice because they fit straight-edged recesses and can be arranged in a line. Select enough thickness to provide useful pull through the material separating the magnet from the tool or steel component. A magnet buried too deeply below a timber surface will lose much of the benefit of its N52 grade.

Fit N52 magnets with care

Plan the magnet orientation before installation. Two magnets intended to attract must present opposite poles to each other. Marking one face before fitting can prevent the frustrating mistake of installing a pair that repel.

Where magnets are bonded into timber, plastic or metal, the recess should be clean, dry and close-fitting. Adhesive can work well for low-impact applications, but a countersunk magnet with a suitable screw gives greater confidence where repeated opening, vibration or load is involved.

Keep magnets away from cards with magnetic strips, sensitive electronics and loose steel swarf. Larger N52 magnets can snap together quickly, chip on impact and trap skin. Wear eye protection when handling multiple magnets or machining recesses nearby, and keep powerful magnets away from children.

Consider heat and the surrounding materials

Standard N52 neodymium magnets are not a universal high-temperature solution. Heat can permanently reduce magnetic performance, so check the stated operating temperature if the magnet will be used near ovens, lighting, motors or heated machinery.

Also consider the material on the other side. Thick mild steel gives the best response. Stainless steel may be weakly magnetic or non-magnetic depending on the grade, while aluminium, brass, copper and timber will not be attracted at all. In those cases, fit a steel strike plate or choose a mechanical fixing method instead.

Start with the space available, the gap you need to bridge and the way the load will act. Then choose the N52 size and format that gives reliable holding without making the finished job harder to use. A well-sized magnet should disappear into the build and simply do its job every time.
